Brand Name: | Texas Instruments |
---|---|
Model Number: | THS4531IDR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | THS4531IDR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Amplifier Driver EMI Filter IC,Texas Instruments EMI Filter IC,THS4531IDR |
ECAD Module | PCB Symbol,Footprint & 3D Model |
Supply and Demand Status | Balance |
Fake Threat In the Open Market | 51 pct. |
Popularity | Medium |
Win Source Part Number | 1107113-THS4531IDR |
Case / Package | 8-SOIC |
Mounting | SMD (SMT) |
Temperature Range - Operating | -40°C to 125°C |
Voltage - Input Offset | 200μV |
Channel Output Current | 25mA |
Supply Voltage - Operating | 2.5 V to 5.5 V, ±1.25 V to 2.75 V |
Gain Bandwidth Product (GBP) | 27MHz |
Slew Rate | 390 V/μs |
Operating Supply Current | 250μA |
Number of Circuits | 1 |
Current - Input Bias | 160nA |
Status | Active |
Packaging | Reel - TR |
Manufacturer | Texas Instruments |
Categories | Integrated Circuits |
Amplifier Type | Differential |
Output Type | Differential, Rail-to-Rail |
-3db Bandwidth | 36MHz |
The THS4531 is a low-power, fully-differential op amp with input common-mode range belowthe negative rail and rail-to-rail output. The device is designed for low-power data acquisitionsystems and high density applications where power consumption and dissipation is critical.
The device features accurate output common-mode control that allows for dc coupling whendriving analog-to-digital converters (ADCs). This control, coupled with the input common-mode rangebelow the negative rail and rail-to-rail output, allows for easy interface from single-endedground-referenced signal sources to successive-approximation registers (SARs), and delta-sigma (ΔΣ)ADCs using only single-supply 2.5 V to 5 V power. The THS4531 is also a valuable tool forgeneral-purpose, low-power differential signal conditioning applications.
The THS4531 is characterized for operation over the extended industrial temperature rangefrom –40°C to +125°C. The following package options are available:
