| Brand Name: | Texas Instruments |
|---|---|
| Model Number: | LM9061QDRQ1 |
| Minimum Order Quantity: | 1 piece |
| Delivery Time: | 2~8 workdays |
| Payment Terms: | T/T |
| Brand: | Texas Instruments | Certificate: | / |
|---|---|---|---|
| Model: | LM9061QDRQ1 | MOQ: | 1 Pc |
| Price: | Negotiated | Delivery: | 2~8 Workdays |
| Payment: | T/T | ||
| High Light: | SMD Mounting EMI Filter IC,TI EMI Filter IC,LM9061QDRQ1 |
||
SMD Mounting EMI Noise Filter IC Texas Instruments / TI LM9061QDRQ1
| ECAD Module | PCB Symbol,Footprint & 3D Model |
| ECCN | EAR99 |
| Country of Origin | Malaysia |
| Halogen Free | Compliant |
| Estimated EOL Date | 2028 |
| Supply and Demand Status | Limited |
| Fake Threat In the Open Market | 53 pct. |
| Popularity | Medium |
| Manufacturer Package | 8-SOIC |
| Package | 8-SOIC (0.154", 3.90mm Width) |
| Mounting | SMD |
| Operating Temperature Range | -40°C ~ 125°C (TJ) |
| Introduction Date | November 24, 2014 |
| Logic Voltage - VIL, VIH | 1.5V, 3.5V |
| Gate Type | N-Channel MOSFET |
| Number of Drivers | 1 |
| Channel Type | Single |
| Win Source Part Number | 1200910-LM9061QDRQ1 |
| Packaging | Reel - TR |
| Family Name | LM9061 |
| Manufacturer | Texas Instruments |
| Categories | Integrated Circuits (ICs) |
| Operating Supply Voltage | 7 V ~ 26 V |
| Driven Configuration | High-Side |
| Series | Automotive, AEC-Q100 |
The LM9061 family consists of charge-pump devices which provides the gate drive to an external power MOSFET of any size configured as a high-side driver or switch. This includes multiple parallel connected MOSFETs for very high current applications. A CMOS logic-compatible ON and OFF input controls the output gate drive voltage. In the ON state, the charge pump voltage, which is well above the available VCC supply, is directly applied to the gate of the MOSFET. A built-in 15-V Zener clamps the maximum gate to source voltage of the MOSFET. When commanded OFF a 110-µA current sink discharges the gate capacitances of the MOSFET for a gradual turnoff characteristic to minimize the duration of inductive load transient voltages and further protect the power MOSFET.
Lossless protection of the power MOSFET is a key feature of the LM9061. The voltage drop (VDS) across the power device is continually monitored and compared against an externally programmable threshold voltage. A small current-sensing resistor in series with the load, which causes a loss of available energy, is not required for the protection circuitry. If the VDSvoltage, due to excessive load current, exceeds the threshold voltage, the output is latched OFF in a more gradual fashion (through a 10-µA output current sink) after a programmable delay time interval.
