Brand Name: | Texas Instruments |
---|---|
Model Number: | INA216A2RSWR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | INA216A2RSWR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | 200 Ampere EMI Filter IC,2000V EMI Filter IC,INA216A2RSWR |
EMI Filter IC Texas Instruments/TI INA216A2RSWR
ECAD Module | PCB Symbol,Footprint & 3D Model |
Supply and Demand Status | Balance |
Fake Threat In the Open Market | 45 pct. |
Popularity | Medium |
Win Source Part Number | 1185819-INA216A2RSWR |
MSL Level | 1 (Unlimited) |
Manufacturer Pack Quantity | 1 |
Family Part Number | INA216 |
Supplier Device Package | 10-UQFN (1.8x1.4) |
Manufacturer Package | 10-UFQFN |
Mounting Style | SMD |
Temperature Range - Operating | -40°C ~ 125°C |
Parts Input Voltage (V) | 1.8V ~ 5.5V |
Accuracy | ±0.05% |
Sensing Method | High-Side |
Function | Current Monitor |
Packaging | Reel |
Manufacturer | Texas Instruments |
Categories | Integrated Circuits |
The INA216 is a high-side voltage output current shunt monitor that can sense drops across shunts at common-mode voltages from +1.8V to +5.5V. Four fixed gains are available: 25V/V, 50V/V, 100V/V, and 200V/V. The low offset of the Zerø-Drift architecture enables current sensing with maximum drops across the shunt as low as 10mV full-scale, or with wide dynamic ranges of over 1000:1.
These devices operate from a single +1.8V to +5.5V power supply, drawing a maximum of 25µA of supply current. The INA216 series are specified over the temperature range of –40°C to +125°C, and offered in a chip-scale package.
