Brand Name: | Texas Instruments |
---|---|
Model Number: | LMV824MTX/NOPB |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | LMV824MTX/NOPB | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | 5.6MHz Amplifier IC Chips,NOPB Amplifier IC Chips,LMV824MTX |
Amplifier IC Chips Texas Instruments/TI LMV824MTX/NOPB
ECAD Module | PCB Symbol,Footprint & 3D Model |
Estimated EOL Date | 2028 |
Is this a common-used part? | Yes |
Popularity | High |
Fake Threat In the Open Market | 64 pct. |
Supply and Demand Status | Balance |
Alternative Parts (Cross-Reference) |
LMV324AMTC14X_NL; MAX4234AUD-T; LMV324AMTC14X_Q; |
Halogen Free | Compliant |
Country of Origin | Malaysia |
ECCN | EAR99 |
Introduction Date | August 01, 1999 |
Family Name | LMV824 |
Case / Package | 14-TSSOP |
Mounting | SMD (SMT) |
Temperature Range - Operating | -40°C to 85°C |
Operating Supply Current | 1mA |
Channel Output Current | 45mA |
Supply Voltage - Operating | 2.5 V to 5.5 V, ±1.25 V to 2.75 V |
Voltage - Input Offset | 3.5mV |
Output Type | Rail-to-Rail |
Number of Circuits | 4 |
Amplifier Type | General Purpose |
Status | Active |
Packaging | Reel - TR |
Manufacturer | Texas Instruments |
Categories | Integrated Circuits |
Current - Input Bias | 100nA |
Gain Bandwidth Product (GBP) | 5.6MHz |
Slew Rate | 2 V/μs |
The LMV821/LMV822/LMV824 op amps bring performance and economy to low voltage, low powersystems. With a 5 MHz unity-gain frequency, at 2.7 V supply, and a 1.4 V/µs slew rate, thequiescent current is only 220 µA per amplifier. They provide rail to rail output (RRO) swing into600 Ω load. The input common-mode voltage range includes ground and the maximum input offsetvoltage is 3.5 mV. They are also capable of easily driving large capacitive loads as indicated inthe applications section.
