| Brand Name: | Texas Instruments |
|---|---|
| Model Number: | OPA388IDBVT |
| Minimum Order Quantity: | 1 piece |
| Delivery Time: | 2~8 workdays |
| Payment Terms: | T/T |
| Brand: | Texas Instruments | Certificate: | / |
|---|---|---|---|
| Model: | OPA388IDBVT | MOQ: | 1 Pc |
| Price: | Negotiated | Delivery: | 2~8 Workdays |
| Payment: | T/T | ||
| High Light: | TDA2030 Amplifier IC Chip,EMI Hardened Amplifier IC Chip,OPA388IDBVT |
||
Amplifier IC Chips Texas Instruments/TI OPA388IDBVT
| Number of channels (#) | 1 |
| Total supply voltage (Max) (+5V=5, +/-5V=10) | 5.5 |
| Total supply voltage (Min) (+5V=5, +/-5V=10) | 2.5 |
| Vos (offset voltage @ 25 C) (Max) (mV) | 0.005 |
| GBW (Typ) (MHz) | 10 |
| Features | EMI Hardened, High Cload Drive, Zero Crossover, Zero Drift |
| Slew rate (Typ) (V/us) | 5 |
| Rail-to-rail | In, Out |
| Offset drift (Typ) (uV/C) | 0.005 |
| Iq per channel (Typ) (mA) | 1.7 |
| Vn at 1 kHz (Typ) (nV/rtHz) | 7 |
| CMRR (Typ) (dB) | 138 |
| Rating | Catalog |
| Operating temperature range (C) | -40 to 125 |
| Input bias current (Max) (pA) | 350 |
| Output current (Typ) (mA) | 60 |
| Architecture | CMOS |
| THD + N @ 1 kHz (Typ) (%) | 0.0005 |
