Brand Name: | Texas Instruments |
---|---|
Model Number: | TXS0108ENMER |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TXS0108ENMER | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | SMbus BOM Electronic Components,MDIO BOM Electronic Components,TXS0108ENMER |
One-Stop Service of MDIO SMbus I2C IC Chip 8 Bits TXS0108ENMER Texas Instruments
IC Electronic Components Texas Instruments/TI TXS0108ENMER
Technology Family | TXS |
Applications | I2C, MDIO, SMbus |
Bits (#) | 8 |
High input voltage (Min) (Vih) | 1 |
High input voltage (Max) (Vih) | 5.5 |
Vout (Min) (V) | 1.4 |
Vout (Max) (V) | 5.5 |
IOH (Max) (mA) | 0 |
IOL (Max) (mA) | 0 |
Rating | Catalog |
This device is an 8-bit non-inverting level translator that uses two separateconfigurable power-supply rails. The A port tracks the VCCA pin supplyvoltage. The VCCA pin accepts any supply voltage between1.4 V and 3.6 V. The B port tracksthe VCCB pin supply voltage. The VCCB pin accepts anysupply voltage between 1.65 V and 5.5 V. Two input supply pins allows for low Voltage bidirectionaltranslation between any of the 1.5 V, 1.8 V, 2.5 V, 3.3 V, and 5 V voltage nodes.
When the output-enable (OE) input is low, all outputs are placed in the high-impedance(Hi-Z) state.
To ensure the Hi-Z state during power-up or power-down periods, tie OE to GND through apull-down resistor. The minimum value of the resistor is determined by the current-sourcingcapability of the driver.
