Brand Name: | Texas Instruments |
---|---|
Model Number: | TMUX646ZECR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TMUX646ZECR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | MIPI BOM Electronic Components,TI BOM Electronic Components,TMUX646ZECR |
One-Stop Service of Voltage Regulator IC Electronic Components TI TMUX646ZECR 1.5V - 5.5V
IC Electronic Components Texas Instruments/TI TMUX646ZECR
Protocols | MIPI |
Configuration | 2:1 SPDT |
Number of channels (#) | 10 |
Bandwidth (MHz) | 6000 |
Supply voltage (Max) (V) | 5.5 |
Supply voltage (Min) (V) | 1.5 |
Ron (Typ) (Ohms) | 6 |
Input/ouput voltage (Min) (V) | 0 |
Input/ouput voltage (Max) (V) | 3.6 |
Supply current (Typ) (uA) | 0.1 |
ESD HBM (Typ) (kV) | 6 |
Operating temperature range (C) | -40 to 85 |
Crosstalk (dB) | -40 |
ESD CDM (kV) | 2 |
ICC (Typ) (uA) | 0.1 |
Input/output continuous current (Max) (mA) | 35 |
COFF (Typ) (pF) | 1.5 |
CON (Typ) (pF) | 1.5 |
Off isolation (Typ) (dB) | -20 |
OFF-state leakage current (Max) (µA) | 0.5 |
Propagation delay (ns) | 40 |
Ron (Max) (Ohms) | 10 |
RON flatness (Typ) (Ohms) | 0.1 |
VIH (Min) (V) | 1 |
VIL (Max) (V) | 0.4 |
The TMUX646 is an optimized 10-channel (5 differential) single-pole, double-throw bi-directional switch for use in high speed applications. The TMUX646 is designed to facilitate multiple MIPI compliant devices to connect to a single CSI/DSI, C-PHY/D-PHY module. The device also supports SATA, SAS, MIPI DSI/CSI, LVDS, RGMII, DDR and Ethernet interfaces.
The device has a bandwidth of 6 GHz, low channel-to-channel skew with little signal degradation, and wide margins to compensate for layout losses. The device’s low current consumption meets the needs of low power applications, including mobile phones and other personal electronics.
