Brand Name: | Texas Instruments |
---|---|
Model Number: | TS3A5017QRGYRQ1 |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TS3A5017QRGYRQ1 | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Automotive TI Electronic Components,165MHz TI Electronic Components,TS3A5017QRGYRQ1 |
Configuration | 4:1 |
Number of channels (#) | 2 |
Power supply voltage - single (V) | 2.5, 3.3 |
Protocols | Analog |
Ron (Typ) (Ohms) | 11 |
CON (Typ) (pF) | 27 |
ON-state leakage current (Max) (µA) | 0.3 |
Bandwidth (MHz) | 165 |
Operating temperature range (C) | -40 to 125 |
Features | Powered-off protection |
Input/output continuous current (Max) (mA) | 128 |
Rating | Automotive |
Supply current (Typ) (uA) | 2.5 |
The TS3A5017-Q1 device is a 2-channel 4:1 multiplexer that is designed to operate from2.3 V to 3.6 V. This device is bidirectional and can handle both digital and analog signals. Thepowered-off protection feature of this device ensures the signal path is high impedance whenVCC = 0 V which simplifies power sequencing and improves system reliability.
