Brand Name: | Texas Instruments |
---|---|
Model Number: | TPSM82480MOPT |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TPSM82480MOPT | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Surface Mounting Power Management ICs,5.5V Power Management ICs,TPSM82480MOPT |
Type: | Drive IC | Price: | Pls Contact Us |
---|---|---|---|
Temperature: | Standing C | Shipping Way: | Post Office And So On |
Application: | Driver/Controller | ||
High Light: |
Surface Mounting Power Management ICs,5.5V Power Management ICs,TPSM82480MOPT |
Power Management ICs Texas Instruments/TI TPSM82480MOPT
ECAD Module | Build or Request PCB Footprint or Symbol |
Supply and Demand Status | Balance |
Popularity | High |
Fake Threat In the Open Market | 63 pct. |
Quantity per package | 1 |
Mounting | Surface Mount |
Operating Temperature Range | -40°C ~ 125°C |
Package | Bulk |
Series | TPS |
Manufacturer | Texas Instruments |
Features | Non-Isolated PoL Module DC DC Converter Output 0.6 ~ 5.5V - - - 6A 2.4V - 5.5V Input |
Package | 24-SMD Module |
Case / Package | 24-QFM (7.9x3.6) |
Win Source Part Number | 937464-TPSM82480MOPT |
Categories | Power Supplies - Board Mount |
The TPSM82480 is a synchronous step-down DC-DC converter module for low profilepoint-of-load power supplies. The input voltage range of 2.4 V to 5.5 V enables operation fromtypical 3.3-V or 5-V interface supplies as well as from backup circuits dropping down as low as 2.4V.
The output current is up to 6 A continuously provided by two phases of 3 A each, whichrun out-of-phase, reducing pulse current noise significantly.
The TPSM82480 provides an automatically entered power save mode to maintain highefficiency down to very light loads. This incorporates an automatic phase adding and sheddingfeature using both or only one phase according to the actual load. The power save mode can beswitched off using the MODE feature.
The device offers a power good signal and an adjustable soft-start period. Also, thedevice features a thermal good signal to indicate excessive internal temperature. The outputvoltage can be changed to a preselected value by VSEL pin. TPSM82480 is able to operate in 100%duty cycle mode.
