Brand Name: | Texas Instruments |
---|---|
Model Number: | TPS562207SDRLR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TPS562207SDRLR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Texas Instruments PMIC Power Management,590kHz PMIC Power Management,TPS562207SDRLR |
D/c: | Newest | Condition: | Original 100% |
---|---|---|---|
Lead Time: | 1-3Days | Shipping Way: | Post Office And So On |
Shipping Ways: | DHL/FEDEX/EMS/CHINA POST OFFICE AND SO ON | ||
High Light: |
Texas Instruments PMIC Power Management,590kHz PMIC Power Management,TPS562207SDRLR |
Power Management ICs Texas Instruments/TI TPS562207SDRLR
Vin (Min) (V) | 4.3 |
Vin (Max) (V) | 17 |
Vout (Min) (V) | 0.806 |
Vout (Max) (V) | 7 |
Iout (Max) (A) | 2 |
Iq (Typ) (uA) | 590 |
Switching frequency (Min) (kHz) | 590 |
Switching frequency (Max) (kHz) | 590 |
Features | Enable, Forced PWM, Soft Start Fixed |
Operating temperature range (C) | -40 to 125 |
Rating | Catalog |
Regulated outputs (#) | 1 |
The TPS562207S is a simple, easy-to-use, 2-A synchronous buck converter in a SOT563 package.
The device is optimized to operate with minimum external components and also optimized to achieve low standby current.
This switch mode power supply (SMPS) device employs D-CAP2 mode control providing a fast transient response and supporting both low-equivalent series resistance (ESR) output capacitors such as specialty polymer and ultra-low ESR ceramic capacitors with no external compensation components.
The TPS562207S operates in Forced Continuous Conduction Mode (FCCM), which maintains fixed switching frequency and output voltage ripple is very small. The TPS562207S is available in a 6-pin 1.6-mm × 1.6-mm SOT563 (DRL) package, and specified from a –40°C to 125°C junction temperature.
