Brand Name: | Texas Instruments |
---|---|
Model Number: | OPA322AIDBVR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | OPA322AIDBVR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | TDA2030 Amplifier Circuit Chips,20MHz Amplifier Circuit Chip,OPA322AIDBVR |
ECAD Module | PCB Symbol,Footprint & 3D Model |
Supply and Demand Status | Sufficient |
Fake Threat In the Open Market | 45 pct. |
Popularity | Medium |
Win Source Part Number | 1084823-OPA322AIDBVR |
Case / Package | SOT-23-5 |
Mounting | SMD (SMT) |
Temperature Range - Operating | -40°C to 125°C |
Supply Voltage - Operating | 1.8 V to 5.5 V, ±0.9 V to 2.75 V |
Channel Output Current | 65mA |
Operating Supply Current | 1.6mA |
Current - Input Bias | 0.2pA |
Output Type | Rail-to-Rail |
Number of Circuits | 1 |
Amplifier Type | General Purpose |
Status | Active |
Packaging | Reel - TR |
Manufacturer | Texas Instruments |
Categories | Integrated Circuits |
Slew Rate | 10 V/μs |
Gain Bandwidth Product (GBP) | 20MHz |
Voltage - Input Offset | 500μV |
The OPAx322x series consists of single, dual, and quad-channel CMOS operational amplifiers featuring low noise and rail-to-rail inputs and outputs optimized for low-power, single-supply applications. Specified over a wide supply range of 1.8 V to 5.5 V, the low quiescent current of only 1.5 mA per channel makes these devices well-suited for power-sensitive applications.
The combination of very low noise (8.5 nV√Hz at 1 kHz), high-gain bandwidth (20 MHz), and fast slew rate (10 V/µs) make the OPAx322x family ideal for a wide range of applications, including signal conditioning and sensor amplification requiring high gains. Featuring low THD+N, the OPAx322x series is also excellent for consumer audio applications, particularly for single-supply systems.
The OPAx322S models include a shutdown mode that allow the amplifiers to be switched from normal operation to a standby current that is typically less than 0.1 µA.
The OPA322 (single version) is available in 5-pin SOT-23 and 6-pin SOT-23, while the OPA2322 (dual version) is offered in 8-pin VSSOP, 10-pin VSSOP, 8-pin SOIC, and 8-pin SON packages. The quad version OPA4322 comes in 14-pin TSSOP and 16-pin TSSOP packages. All versions are specified for operation from –40°C to +125°C.
