Brand Name: | Texas Instruments |
---|---|
Model Number: | TPS25940ARVCT |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TPS25940ARVCT | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | SMD Mounting Texas Instruments Amplifier IC,TI Texas Instruments Amplifier IC,TPS25940ARVCT |
Amplifier IC Chips Texas Instruments/TI TPS25940ARVCT
ECAD Module | PCB Symbol,Footprint & 3D Model |
Halogen Free | Compliant |
Estimated EOL Date | 2031 |
Alternative Parts (Cross-Reference) |
TPS25940ARVCR; |
ECCN | EAR99 |
Supply and Demand Status | Balance |
Fake Threat In the Open Market | 53 pct. |
Popularity | Medium |
Feature Pins | DEVSLP, dVdT, EN/UVLO, /FLT, ILIM, IMON, OVP, PGOOD, PGTH |
Manufacturer Package | 20-WQFN (4x3) |
Win Source Part Number | 797903-TPS25940ARVCT |
Mounting | SMD |
Operating Supply Current | 202μA |
Operating Temperature Range | -40°C ~ 85°C |
Family Name | TPS25940A |
Country of Origin | China, Malaysia, Philippines |
Package | 20-WFQFN Exposed Pad |
Features | Auto Retry, Thermal Limit |
Applications | General |
Internal Switch(s) | Yes |
Number of Channels | 1 |
Current - Output (Maximum) | 5.3A |
Operating Supply Voltage | 2.7 V ~ 18 V |
Manufacturer | Texas Instruments |
Categories | Integrated Circuits (ICs) |
Programmable Features | Current Limit, OVP, Slew Rate, UVLO |
Type | Hot Swap Controller |
Packaging | Reel package |
The TPS25940 eFuse Power Switch is a compact, feature rich power management device with a full suite of protection functions, including a low power DevSleep™ mode that supports compliance with the SATA™ Device Sleep standard. The wide operating range allows control of many popular DC bus voltages. Integrated back to back FETs provide bidirectional current control making the device well suited for systems with load side holdup energy that must not drain back to a failed supply bus.
Load, source and device protection are provided with many programmable features including overcurrent, dVo/dt ramp and overvoltage, undervoltage thresholds. For system status monitoring and downstream load control, the device provides PGOOD, FLT and precise current monitor output. Precise programmable undervoltage, overvoltage thresholds and the low IQDevSleep mode simplify SSD power management design.
The TPS25940 monitors V(IN) and V(OUT) to provide true reverse current blocking when V(IN) < (V(OUT) - 10 mV). This function supports swift changeover to a boosted voltage energy storage element in systems where backup voltage is greater than bus voltage.
