Brand Name: | Texas Instruments |
---|---|
Model Number: | CC1121RHBR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | CC1121RHBR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | SPI Texas Instruments Power Modules,200kbps Texas Instruments Power Modules,CC1121RHBR |
Top Rated SPI Texas Instruments Power Modules IGBT CC1121RHBR 200kbps
IGBT Power Module Texas Instruments/TI CC1121RHBR
ECAD Module | PCB Symbol,Footprint & 3D Model |
Country of Origin | Philippines |
Halogen Free | Compliant |
Estimated EOL Date | 2028 |
Alternative Parts (Cross-Reference) |
CC1121RHBT; |
Supply and Demand Status | Limited |
Fake Threat In the Open Market | 45 pct. |
Popularity | Medium |
Package | 32-VFQFN Exposed Pad |
Operating Temperature Range | -40°C ~ 85°C |
Current - Transmitting | 26mA ~ 54mA |
Current - Receiving | 17mA ~ 23mA |
Win Source Part Number | 1159398-CC1121RHBR |
GPIO | 4 |
ECCN | 5A991.b |
Memory Size | 4kB ROM, 256B RAM |
Sensitivity | -120dBm |
Power - Output | 16dBm |
Family Name | CC1121 |
Frequency | 164MHz ~ 192MHz, 274MHz ~ 320MHz, 410MHz ~ 480MHz, 820MHz ~ 960MHz |
Modulation | 2FSK, 2GFSK, 4FSK, 4GFSK, MSK, OOK |
Operating Supply Voltage | 2 V ~ 3.6 V |
Type | TxRx + MCU |
Packaging | Reel - TR |
Manufacturer | Texas Instruments |
Categories | RF/IF and RFID |
Serial Interfaces | SPI |
Data Rate (Maximum) | 200kbps |
RF Family/Standard | General ISM |
The CC1121 device is a fully integrated single-chip radio transceiver designed for high performance at very low-power and low-voltage operation in cost-effective wireless systems. All filters are integrated, thus removing the need for costly external SAW and IF filters. The device is mainly intended for the ISM (Industrial, Scientific, and Medical) and SRD (Short Range Device) frequency bands at 274–320 MHz, 410–480 MHz, and 820–960 MHz.
The CC1121 device provides extensive hardware support for packet handling, data buffering, burst transmissions, clear channel assessment, link quality indication, and Wake-On-Radio. The main operating parameters of the CC1121 device can be controlled through an SPI interface. In a typical system, the CC1121 device will be used with a microcontroller and only a few external passive components.
