| Brand Name: | Texas Instruments |
|---|---|
| Model Number: | TCAN334GDCNR |
| Minimum Order Quantity: | 1 piece |
| Delivery Time: | 2~8 workdays |
| Payment Terms: | T/T |
| Brand: | Texas Instruments | Certificate: | / |
|---|---|---|---|
| Model: | TCAN334GDCNR | MOQ: | 1 Pc |
| Price: | Negotiated | Delivery: | 2~8 Workdays |
| Payment: | T/T | ||
| High Light: | IGBT Texas Instruments Components,5Mbps Texas Instruments Components,TCAN334GDCNR |
||
IGBT Texas Instruments Components 5Mbps TI TCAN334GDCNR Power Module
IGBT Power Module Texas Instruments/TI TCAN334GDCNR
| Protocols | CAN, CAN FD |
| Number of channels (#) | 1 |
| Supply voltage (V) | 3 to 3.6 |
| Bus fault voltage (V) | -14 to 14 |
| Signaling rate (Max) (Mbps) | 5 |
| Rating | Catalog |
| Operating temperature range (C) | -40 to 125 |
| Low power mode | Standby, Shutdown |
| Common mode voltage (V) | -12 to 12 |
| Isolated | No |
The TCAN33x family of devices is compatible with the ISO 11898 High Speed CAN (ControllerArea Network) Physical Layer standard. TCAN330, TCAN332, TCAN334 and TCAN337 are specified for datarates up to 1 Mbps. Pending the release of the updated version of ISO 11898-2 including CAN FD,additional timing parameters defining loop delay symmetry are specified for the TCAN330G, TCAN332G,TCAN334G and TCAN337G devices. The devices include many protection features including driver andreceiver Dominant Time Out (DTO) providing CAN network robustness. Integrated 12 kV IEC-61000-4-2ESD Contact Discharge protection eliminates the need of additional components for system levelrobustness.
The use of single 3.3-V supply enables the transceivers to directly interface with 3.3-VCAN controllers/MCUs. In addition, these devices are fully compatible with other 5-V CANtransceivers on the same bus.
These devices have excellent EMC performance due to matched Dominant and Recessive CommonModes. Ultra low power Shutdown and Standby modes make these devices attractive for battery poweredapplications.
This family of devices is available in standard 8-pin SOIC packages for drop-incompatibility and in small SOT-23 packages for space-constrained applications.
