Brand Name: | Texas Instruments |
---|---|
Model Number: | TLA2022IRUGR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TLA2022IRUGR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | 200W IGBT Gate Driver Module,I2C IGBT Gate Driver Module,TLA2022IRUGR |
New Arrivals of 200W IGBT Module Driver Circuit I2C TLA2022IRUGR Texas Instruments
IGBT Power Module Texas Instruments/TI TLA2022IRUGR
Resolution (Bits) | 12 |
Number of input channels | 1 |
Sample rate (Max) (kSPS) | 3.3 |
Interface type | I2C |
Architecture | Delta-Sigma |
Input type | Differential, Single-Ended |
Multi-channel configuration | — |
Rating | Catalog |
Reference mode | Int |
Input range (Max) (V) | 5.5 |
Input range (Min) (V) | 0 |
Features | Oscillator, PGA, Small Size |
Operating temperature range (C) | -40 to 85 |
Power consumption (Typ) (mW) | 0.3 |
Analog voltage AVDD (Min) (V) | 2 |
Analog voltage AVDD (Max) (V) | 5.5 |
Digital supply (Min) (V) | 2 |
Digital supply (Max) (V) | 5.5 |
The TLA2021, TLA2022, and TLA2024 devices (TLA202x) areeasy-to-use, low-power, 12-bitdelta-sigma (ΔΣ) analog-to-digital converters (ADCs) targeted for any type of system-monitoringapplications (such as supply or battery voltage supervision, current sensing, or temperaturemeasurements). Offered in an ultra-small, leadless, 10-pin X2QFN package, theTLA2021 and TLA2022 are single-channel ADCs while theTLA2024 features a flexible input multiplexer (MUX) with two differential orfour single-ended input measurement options.
The TLA202x integrate a voltage reference and oscillator.Additionally, the TLA2022 and TLA2024 include a programmable gain amplifier (PGA) withselectable input ranges from ±256 mV to ±6.144 V, enabling both large- and small-signalmeasurements.
The TLA202x communicate via anI2C-compatible interface and operate in either continuous or single-shotconversion mode. The devices automatically power down after one conversion in single-shotconversion mode, significantly reducing power consumption during idle periods.
All of these features, along with a wide operating supply voltage range, make theTLA202x suitable for power- and space-constrained, system-monitoringapplications.
