Brand Name: | Texas Instruments |
---|---|
Model Number: | CDCDB800RSLR |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | CDCDB800RSLR | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | 200W IGBT Power Module,250MHz IGBT Power Module,CDCDB800RSLR |
Stock 200W IGBT Power Module 250MHz CDCDB800RSLR Texas Instruments
IGBT Power Module Texas Instruments/TI CDCDB800RSLR
Function | Clock buffer, Differential |
Additive RMS jitter (Typ) (fs) | 38 |
Output frequency (Max) (MHz) | 250 |
Number of outputs | 8 |
Output supply voltage (V) | 3.3 |
Core supply voltage (V) | 3.3 |
Output skew (ps) | 50 |
Features | 1:8 fanout, PCIe Gen 1-5 compliant, DB800ZL compliant, SMBus control, OE# control, Individual output enable control |
Operating temperature range (C) | -40 to 105 |
Rating | Catalog |
Output type | LP-HCSL |
Input type | LP-HCSL |
Fail-safe input
Programmable output slew rate control
The CDCDB800 is a 8-output LP-HCSL, DB800ZL-compliant, clock buffer capable of distributing the reference clock for PCIe Gen 1-5, QuickPath Interconnect (QPI), UPI, SAS, and SATA interfaces. The SMBus interface and eight output enable pins allow the configuration and control of all eight outputs individually. The CDCDB800 is a DB800ZL derivative buffer and meets or exceeds the system parameters in the DB800ZL specification. It also meets or exceeds the parameters in the DB2000Q specification. The CDCDB800 is packaged in a 6-mm × 6-mm, 48-pin VQFN package.
