Brand Name: | Texas Instruments |
---|---|
Model Number: | TPS2069DDBVT |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | TPS2069DDBVT | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Current Limit Power Switch IC,Texas Instruments Power Switch IC,TPS2069DDBVT |
Light Source: | LED | Ip Rating: | IP65/IP66/IP67 |
---|---|---|---|
Item Type: | Street Lights | Light Source: | Epistar |
Product Name: | New Design 56W Led Light Components For Led Industrial Light | ||
High Light: |
TPS2069DDBVT Power Switch IC,Texas Instruments Power Switch IC,Driver Current Limit Switch IC |
Display Driver IC Texas Instruments/TI TPS2069DDBVT
Vin (Min) (V) | 4.5 |
Vin (Max) (V) | 5.5 |
Continuous current (Max) (A) | 1.5 |
Current limit (A) | 2.15 |
Product type | Fixed current limit, Power switch |
Operating temperature range (C) | -40 to 125 |
Enable | Active High |
Number of switches | 1 |
Rating | Catalog |
The TPS2069D power-distribution switch family is intended for applications such as USB where heavy capacitive loads and short circuits are likely to be encountered. The device can continuously deliver up to 1.5 A output current.
The TPS2069D limits the output current to a safe level by operating in a constant-current mode when the output load exceeds the current limit threshold. This provides a predictable fault current under all conditions. The fast overload response time eases the burden on the main 5-V supply to provide regulated power when the output is shorted. The power-switch rise and fall times are controlled to minimize current surges during turnon and turnoff.
