Brand Name: | Analog Devices Inc. |
---|---|
Model Number: | AD589SH |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Analog Devices Inc. | Certificate: | / |
---|---|---|---|
Model: | AD589SH | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Analog Mobile Phone Flash,ADI Mobile Phone Flash,AD589SH |
Analog Integrated Circuits ICs Memory Mobile Phone Flash ADI AD589SH
Memory IC Chip Analog Devices Inc./ADI AD589SH
ECAD Module | PCB Footprint and Symbol |
Supply and Demand Status | Limited |
Fake Threat In the Open Market | 72 pct. |
Popularity | High |
Is this a common-used part? | Yes |
Win Source Part Number | 076931-AD589SH |
Case / Package | TO-51-2 |
Mounting | Through Hole |
Temperature Range - Operating | -55°C to 125°C (TA) |
Current - Cathode | 50μA |
Noise - 10Hz to 10kHz | 5μVrms |
Temperature Coefficient | 100ppm/°C |
Tolerance | -2.83%, +1.22% |
Output Type | Fixed |
Reference Type | Shunt |
Status | Active |
Packaging | Bulk |
Manufacturer | Analog Devices Inc. |
Categories | Integrated Circuits |
Nominal Output Voltage (Min/Fixed) | 1.235V |
Output Current | 5mA |
PRODUCT DESCRIPTION
The AD589 is a 2-terminal, low cost, temperature compensated band gap voltage reference that provides a fi xed 1.23 V output voltage for input currents between 50 A and 5.0 mA.
The high stability of the AD589 is primarily dependent upon the matching and thermal tracking of the on-chip components.Analog Devices’ precision bipolar processing and thin-fi lm technology combine to provide excellent performance at low cost.
Additionally, the active circuit produces an output impedance 10 lower than the typical low-TC Zener diodes. This feature allows operation with no external components required to maintain full accuracy under changing load conditions.
The AD589 is available in seven versions. The AD589J, AD589K, AD589L, and AD589M grades are specifi ed for 0°C to +70°C operation, while the AD589S and AD589T grades are rated for the full –55°C to +125°C temperature range. All grades are available in a metal can (H-02) package. The AD589J is also available in an 8-lead SOIC package.
