Brand Name: | Texas Instruments |
---|---|
Model Number: | DAC8760IPWP |
Minimum Order Quantity: | 1 piece |
Delivery Time: | 2~8 workdays |
Payment Terms: | T/T |
Brand: | Texas Instruments | Certificate: | / |
---|---|---|---|
Model: | DAC8760IPWP | MOQ: | 1 Pc |
Price: | Negotiated | Delivery: | 2~8 Workdays |
Payment: | T/T | ||
High Light: | Power Management Electronic IC Chip,FPGA Electronic IC Chip,DAC8760IPWP |
ORIGIN NEW ARRIVE DAC8760IPWP Power Management ICs FPGA PCB ' A
Categories | Integrated Circuits (ICs) |
Estimated Pruduction Lead Time | 34 Weeks |
Features | 16 Bit Digital to Analog Converter 1 24-HTSSOP |
Manufacturer | Texas Instruments |
Package | Tube |
Operating Temperature Range | -40°C ~ 125°C |
Mounting | Surface Mount |
Package | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
Case / Package | 24-HTSSOP |
Family Name | DAC8760 |
MSL Level | 3 (168 Hours) |
REACH Status | REACH Unaffected |
ECCN | EAR99 |
HTSUS | 8542.39.0001 |
Other Part Number | 296-46509-5, DAC8760IPWP-ND |
Quantity per package | 60 |
Fake Threat In the Open Market | 33 pct. |
Popularity | High |
Supply and Demand Status | Balance |
Features:
• Designed to operate from 5.5 V ≤ VPWR ≤ 28 V
• Switch input voltage: (33975: -14 to 38 V) (33975A: -14 to 40 V)
• Interfaces to microprocessor using 3.3 V/5.0 V SPI protocol
• Selectable wake-up on change of state
• 14 switch-to-ground inputs
• 8 programmable inputs (switches to battery or ground)
• Selectable wetting current (32 mA or 4.0 mA for switch-to-ground
inputs)
• Sleep State current VPWR 100 μA, VDD 20 μA
• Pb-free packaging designated by suffix code EK
Single-Channel, 12- and 16-Bit Programmable Current Output and Voltage Output Digital-to-Analog Converter for 4-mA to 20-mA Current Loop Applications
16 Bit Digital to Analog Converter 1 24-HTSSOP
The DAC8760IPWP DAC converter, developed by Texas Instruments, is the ideal tool for converting binary information into variable analog signals such as audio and video. It has a current|voltage output. This device&s;s digital interface is serial (4-wire, spi, qspi, microwire). This device is based on Resistor-String architecture. This DAC has a resolution of 16bit. It has a maximum of ±18 V. This DAC has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device comes in tube packaging. This device uses one or two power supplies.
